GV-AI System V2 RevB
GV-AI System V2 (Rev. B), equipped with Intel Core Processor, is designed to boost the AI deep learning performance for video analysis applications in video surveillance, access control, and retail sectors. GV-AI System V2 (Rev. B) comes with 2 graphics outputs (HDMI, DisplayPort) to support up to 2 monitors simultaneously. Up to four 3.5" HDDs can be installed in the system to meet the storage demand.
Software Supported: GV-AI FR / GV-AI Server / GV-AI Guard / Other GV-Software (by request)
Software Supported: GV-AI FR / GV-AI Server / GV-AI Guard / Other GV-Software (by request)
- Powered by Intel Core Processor
- 64-bit Windows 10 IoT Enterprise
- Support for GPU Decoding
- 2 graphics outputs (HDMI and DisplayPort) to support up to 2 monitors simultaneously
- 4U size (469 x 430 x 176 mm / 18.47 x 16.93 x 6.93 in)
- Redundant power supply (optional)
- GV-AI Accelerator Module to enhance PVD detection channels and reduce CPU demand (optional)
Note:
- If you are in an area with unstable voltage, make sure to install an automatic voltage regulator (AVR) or a UPS power supply with AVR function, to maintain a constant voltage.
- All damages to the power supply caused by unstable voltage are not included in the 2-year warranty service.
- All specifications are subject to change with notice.
Note:
- If you are in an area with unstable voltage, make sure to install an automatic voltage regulator (AVR) or a UPS power supply with AVR function, to maintain a constant voltage.
- All damages to the power supply caused by unstable voltage are not included in the 2-year warranty service.
- All specifications are subject to change with notice.
Model No | Name | Details | |
---|---|---|---|
GV-AI Accelerator Module | GV-AI Accelerator Module increases the number of PVD motion detection channels in GV-VMS or GV-AI Guard. | ||
Redundant Power Supply | When 1 module of the redundant power supply is down, the other module can still supply full power to the system. Output: 800 W Input: 96-264 V AC, 47-63 Hz, 12-6A |
- GV-AI System V2 (Rev. B)
- Power Cord (by regions)
- Screw Kit
- Download Guide
- Warranty Card
Note:
- If you are in an area with unstable voltage, make sure to install an automatic voltage regulator (AVR) or a UPS power supply with AVR function, to maintain a constant voltage.
- All damages to the power supply caused by unstable voltage are not included in the 2-year warranty service.
- All specifications are subject to change with notice.
Note:
- If you are in an area with unstable voltage, make sure to install an automatic voltage regulator (AVR) or a UPS power supply with AVR function, to maintain a constant voltage.
- All damages to the power supply caused by unstable voltage are not included in the 2-year warranty service.
- All specifications are subject to change with notice.
- GV-AI System V2 (Rev. B)
- Power Cord (by regions)
- Screw Kit
- Download Guide
- Warranty Card
Note:
- If you are in an area with unstable voltage, make sure to install an automatic voltage regulator (AVR) or a UPS power supply with AVR function, to maintain a constant voltage.
- All damages to the power supply caused by unstable voltage are not included in the 2-year warranty service.
- All specifications are subject to change with notice.
