GV-Hot Swap VMS System V5 RevE-2U,4-Bay

The GV-Hot Swap VMS System V5 (Rev. E) features a powerful data storage capacity. It comes with a selection of 4U (20-bay), 3U (16 / 8-bay), or 2U (4-bay) and hot-swappable SATA mobile racks. Depending on HDD size, the GV-Hot Swap VMS System V5 (Rev. E) can store up to 200 terabytes of recorded data. Support for hot-swapping makes data storage and management more convenient.

GeoVision Surveillance System empowers the GV-Hot Swap VMS System V5 (Rev. E) with a maximum of 64 audio and video channels. Its networking capability makes remote access and control of the system possible. Additionally, its compatibility with other GeoVision accessories can cater to any kind of needs or budgets. By extending the compatibility to the third-party IP devices (license required), GV-VMS software provides a pure IP solution to GV-Hot Swap VMS System V5 (Rev. E).
  • Powered by Intel Core i7 Processor
  • 64-bit Windows 10 IoT Enterprise
  • Support H.265 CPU and GPU decoding
  • Support 64-channel GV-VMS (pure IP surveillance)
  • Three-monitor display
  • Maximum storage capacity up to 200 TB (4U 20-Bay) / 160 TB (3U 16-Bay) / 80 TB (3U 8-Bay) / 40 TB (2U 4-Bay)
  • Hot-swap status LED panel
  • Dual Gigabit LAN ports
  • 4U (20-bay), 3U (16 / 8-bay), or 2U (4-bay) hot-swap SATA HDDs for data storage
  • Extreme performance for GV-VMS operation
  • Pre-installed SSD for recovery
  • Compatible with full selections of GeoVision accessories
  • CE, FCC compliant

Note:
  • Specifications are subject to change without notice.


Note:
  • Specifications are subject to change without notice.
Model No Name Details
GV-COM V3 This unit can add 1 RS-485 port to your computer through a USB connector.
GV-IO Box Series GV-IO Box series provides 4 / 8 / 16 inputs and relay outputs, and supports both DC and AC output voltages, with optional support for Ethernet module and 4E additionally supporting PoE connection.
GV-Joystick V2 GV-Joystick V2 facilitates the PTZ camera control. It can be either plugged into the GV-Hot Swap DVR/NVR V5 for independent use or connected to GV-Keyboard to empower the operation.
GV-Keyboard V3 The GV-Keyboard V3 is designed to program and operate GV-System and GV-VMS, and it can also be connected with PTZ cameras directly for PTZ control.
GV-IR Remote Control The GV-IR Remote Control provides easy control of the GV-Hot Swap DVR / NVR / VMS System.
  • GV-Hot Swap VMS System V5 x 1
  • AC Power Cord x 1
  • Self-Stick Rubber Pad x 4
  • Documents Download Guide
  • Warranty Card​
