GV-Hot Swap Recording Server System V5 RevE-4U,20-Bay GV-Hot Swap Recording Server System V5 RevE-4U,20-Bay

GV-Hot Swap Recording Server System V5 RevE-4U,20-Bay

The GV-Hot Swap Recording Server System is a video streaming server supported by a powerful data storage capacity and designed for large-scale video surveillance deployments. It comes with a selection of 4U (20-bay) or 3U (16-bay) and hot-swappable SATA mobile racks. Depending on the HDD size, the GV-Hot Swap Recording Server System can store up to 200 terabytes of recorded data.

In addition, it can simultaneously distribute up to 300 channels to its clients which include GV-System (DVR/NVR system), GV-GIS (geographic information system), GV-Mobile Server, GV-Control Center (central monitoring system), Multi View (viewing software) and GV-VMS. GV-Recording Server can also send text notifications to one GV-VSM (Vital Sign Monitor) when alert conditions occur. Using the GV-Recording Server, the desired frame rates can be reached while the CPU loading and the bandwidth usage of IP video devices are significantly reduced.

In some areas or countries, you may like to install 3G wireless Internet module (e.g. GPRS/UMTS) on the GV-HD Video Encoder or GV-Compact DVR but have the problem to obtain a public IP address from ISP. The Passive connection method of GV-Recording Server can solve the public IP issue by accepting the connection request from the GV-HD Video Encoder or GV-Compact DVR, and then distribute the video streaming to clients.
The GV-Recording Server provides you with a secure and affordable remote backup solution with the GV-Backup Center, GV-Failover Server and GV-Redundant Server.
  • 64-bit Windows 10 IoT Enterprise
  • Powered by Intel Core i7 Processor
  • 20 hot-swappable SATA drive bays for data storage
  • Maximum storage capacity of up to 200 TB (4U 20-Bay) / 160 TB (3U 16-Bay)
  • Simultaneous receiving and recording up to 128 IP channels
  • Distributing up to 300 IP channels of video to clients
  • 3 Gigabit LAN ports
  • Two USB 2.0 ports and six USB 3.1 ports
  • Pre-installed SSD for recovery
  • Web interface to remotely configure and monitor GV-Recording Server
  • Two-way audio communication (only for GV-IP devices through active connection)
  • Support for third-party IP video devices (Sony, Axis, VIVOTEK, Panasonic, HikVision, Arecont Vision)
  • Support for ONVIF, PSIA and RTSP protocols
  • Multiple (31) languages
  • Redundant power supply (optional)
  • Supported RAID type:0,1,3,5,6,10,00,30,50,60,100 Single Disk or JBOD (optional)

Note:
  • Specifications are subject to change without notice.


Note:
  • Specifications are subject to change without notice.
Số model Tên gọi Chi tiết
Redundant Power Supply The Redundant Power Supply comes with 2 hot-swap modules for 3U models and for 4U models. When 1 module is down, the other module can still supply full power to the system.
- 3U 8 Bays models: 460W 1+1 mode; 100~240V, 47~63HZ
- 3U 16 Bays models: 550W 1+1 mode; 100~240V, 47~63HZ
- 4U 20 Bays models: 800W 1+1 modes; 90~264V, 47~63HZ
RAID Card The supported RAID types include 0,1,3,5,6,10,00,30,50,60,100 Single Disk or JBOD.
  • GV-Hot Swap Recording Server System x 1
  • AC Power Cord x 1
  • Self-Stick Rubber Pad x 4
  • Documents Download Guide
  • Warranty Card​

Note:
  • Specifications are subject to change without notice.

Note:
  • Specifications are subject to change without notice.
Model No. Ordering Part No. Description SKU No.
