GV-MD8710-FD

8MP H.265 Low Lux WDR Pro Face Detection IR Motorized IP Dome

GV-MD8710-FD is specifically designed for face detection. The camera is equipped with a WDR Pro, an automatic IR-cut filter and IR LEDs for day and night surveillance. With its motorized varifocal lens, the user can zoom and focus the camera from the Web interface. The camera can support H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. For night operations, the camera allows up to 30 m (98.4 ft) IR effective distance. Adjustable in 3 axis (pan, tilt and rotate), it offers smart surveillance solutions with all the essential features and excellent image quality.

Models

ModelGV-MD8710-FD
IrisP-Iris
Focal Length (mm)4~8mm
Horizontal FOV112°~61°
Maximum ApertureF/1.44
Image Format1/2.5"
  • 1/2" progressive scan low lux CMOS sensor
  • Min. illumination at 0.03 lux
  • Triple streams from H.265, H.264 and MJPEG
  • Up to 30 fps at 3840 x 2160
  • P-Iris for auto iris adjustment
  • Intelligent IR
  • IR distance up to 30 m (98.4 ft)
  • Two-way audio
  • Built-in micro SD card slot (SDHC/SDXC, Class 10) for local storage
  • Recording assigned by GV-Edge Recording Manager (Windows & Mac version)
  • Wide Dynamic Range Pro (WDR Pro)
  • 3-axis mechanism (pan / tilt / rotate)
  • Face Detection
  • 3D noise reduction
  • Smart streaming
  • Defog
  • Privacy mask
  • IP address filtering
  • DC 12V / PoE (IEEE 802.3af)
  • Day and Night function (with removable IR-cut filter)
  • Supports iPhone, iPad, Android & 3GPP
  • 31 languages on Web interface
  • ONVIF (Profile S) conformant
  • TAICS IoT Cyber Security certified

Note:
  • Face detection requires GV-VMS 18.1 or later.
  • Specifications are subject to change without notice.


Note:
  • Face detection requires GV-VMS 18.1 or later.
  • Specifications are subject to change without notice.
Model No Name Details
GV-Mount100 Straight Tube and Junction Box Kit Dimensions: 200 x 170 x 257.5 mm (7.9 x 6.7 x 10.1")
Weight: 3.17 kg (6.99 lb)
GV-Mount101 Straight Tube Kit Dimensions: 219 x 125 x 332 mm (8.6 x 4.9 x 13.1")
Weight: 1.8 kg (3.97 lb)
GV-Mount200 Wall Pendant Tube Dimensions: 225 x 140 x 250 mm (8.9 x 5.5 x 9.8")
Weight: 900 g (1.98 lb)
GV-Mount203 Wall Pendant Tube and Junction Box Kit Dimensions: 315 x 195.5 x 225 mm (12.4 x 7.7 x 8.9")
Weight: 2.95 kg (6.5 lb)
GV-Mount300-1 Convex Corner Adapter Kit Dimensions: 238.6 x 395.2 x 210 mm (9.4 x 15.5 x 8.2")
Weight: 4.27 kg (9.41 lb)
GV-Mount310-1 Concave Corner Adapter Kit Dimensions: 111.2 x 369.9 x 210 mm  (4.37 x 14.5 x 8.2")
Weight: 2.96 kg (6.53 lb)
GV-Mount400-1 Pole Mount Bracket Kit (Ø 4 ~ 6") Bracket: 68.4 x 240 x 163 mm (2.69 x 9.44 x 6.41")
Weight: 1.70 kg (3.75 lb)
Steel Strap Diameter: Ø 4 ~ 6"
GV-Mount410-1 Pole Mount Bracket Kit (Ø 6 ~ 7.5") Bracket: 68.4 x 240 x 163 mm (2.69 x 9.44 x 6.41")
Weight: 1.70 kg (3.75 lb)
Steel Strap Diameter: Ø 6 ~ 7.5"
GV-Mount702 Extension Tube Four options are available.
Dimensions: Ø 5.4 x 10 or 20 or 30 or 50 cm
(Ø 2.1 x 3.9 or 7.9 or 11.8 or 19.7")
Weight: 180 g or 390 g or 550 g or 800 g
(0.4 lb or 0.86 lb or 1.21lb or 1.76 lb)
GV-Mount909 Wall Mount Bracket Dimensions: 170 x 150 x 110 mm (6.7 x 5.9 x 4.3")
Weight: 0.61 kg (1.34 lb)
GV-Mount910 Power Box Mount Bracket Dimensions: 112 x 98 x 7.5 mm (4.4 x 3.9 x 0.3")
Weight: 105 g (0.23 lb)
GV-Mount913 Power Box Mount Bracket Dimensions: Ø 146 x 7.5 mm (Ø 5.7 x 0.3")
Weight: 180 g (0.4 lb)
GV-Mount915 In-Ceiling Mounting Kit Dimensions: Ø 172.5 x 63.8 mm (Ø 7.04 x 2.5")
Weight: 424 g (0.93 lb)
GV-Mount917 Dome Housing Dimensions: Ø 186 x 97.5 mm (Ø 7.3 x 3.8")
Weight: 948 g (2.09 lb)
GV-PA191 PoE Adapter Power over Ethernet (PoE) Adapter The GV-PA191 is a Power over Ethernet (PoE) adapter designed to provide power to the IP device through a single Ethernet cable.
GV-POE Switch The GV-POE Switch is designed to provide power along with network connection for IP devices. The GV-POE Switch is available in various models with different numbers and types of ports.
Power Adapter Contact our sales representatives for the countries and areas supported.
  • H.265 IR IP Dome
  • Screw x 3
  • Screw Anchor x 3
  • Torx Wrench
  • Shielding Ground Wire
  • I/O Wire
  • Installation Sticker
  • Download Guide
  • Warranty Card

Note:
  • Face detection requires GV-VMS 18.1 or later.
  • Specifications are subject to change without notice.

Note:
  • Face detection requires GV-VMS 18.1 or later.
  • Specifications are subject to change without notice.
