GV-PPTZ7300

7MP H.264 Low Lux WDR Panoramic PTZ IP Camera

GV-PPTZ7300 is a 2-in-1 panoramic PTZ IP camera that includes a 5 MP fisheye panoramic camera and a 2 MP IP Speed Dome. The fisheye camera allows you to monitor all angles of a location, while the speed dome can instantly point toward an area with just one click on the fisheye live view. Without installing any software, you can watch live view and utilize functions such as motion detection, privacy mask, and alert notification through the Web interface.
  • Panoramic fisheye camera (FE) integrated with a PTZ speed dome (SD)
  • FE: 1/2.5" progressive scan CMOS
    SD: 1/2.86" progressive scan CMOS
  • Dual streams from H.264 and MJPEG
  • FE: Up to 10 fps at 2560 × 1920
    SD: Up to 30 fps at 1920 x 1080
  • FE: Day and night (Electronic)
    SD:Day and night function with IR-cut filter
  • FE: Wide Dynamic Range (WDR)
    SD: Wide Dynamic Range Pro (WDR Pro)
  • Vandal resistance (IK10 for metal and polycarbonate casing)
  • Ingress protection (IP67)
  • Wide temperature tolerance (-40°C ~ 50°C / -40°F ~ 122°F)
  • 2 built-in micro SD card slots (SD/SDHC) for local storage (1 each for FE and SD)
  • 4 sensor inputs and 1 alarm output
  • DC 24V / AC 24V / High PoE (PoE++, 40 W)
  • FE: Provides 360° panorama view
  • SD: 10x optical zoom and 32x digital zoom
  • SD: pan 355° and tilt from -15° to 195°
  • SD: Preset speed at up to 460°/sec
  • SD: PTZ movement (Preset, Sequence, Auto Pan, Cruise and Tour)
  • Two-way audio
  • 2D noise reduction
  • Defog
  • Tampering alarm
  • Privacy mask
  • Visual automation
  • Text overlay
  • 31 languages on Web interface
  • ONVIF (Profile S) conformant

Note:
  • Optional GV-PA901 PoE Adapter is required for applying PoE function.
  • Specifications are subject to change without notice.


Note:
  • Optional GV-PA901 PoE Adapter is required for applying PoE function.
  • Specifications are subject to change without notice.
Model No Name Details
GV-Mount102 Straight Tube Box Mount Dimensions: 256 x 256 x 316 mm (10.1 x 10.1 x 12.4")
Weight: 6.6 kg (14.6 lb)
GV-Mount207 Pendant Tube Dimensions: 151.6 x 203.6 x 302.8 mm / (5.97 x 8.02 x 11.92")
Weight: 1.43 kg (3.15 lb)
GV-Mount 208-1 Swan Neck Mount Dimension: 1043 x 565 x 256 mm (41.06 x 22.24 x 10.08")
Weight: 10.6 kg (23.37 lb)
GV-Mount300 Convex Corner Adapter Kit Dimensions: 238.6 x 409.5 mm (9.4 x 16.1")
Weight: 4.27 kg (9.41 lb)
GV-Mount310 Concave Corner Adapter Kit Dimensions: 123.3 x 393.1 mm (4.9 x 15.5")
Weight: 2.96 kg (6.53 lb)
GV-Mount400 Pole Mount Bracket Kit (Ø 4 ~ 6) Bracket: 241 x 161 mm (9.5 x 6.3")
Weight: 1.70 kg (3.75 lb)
Steel Strap Diameter: Ø 4 ~ 6"
GV-Mount410 Pole Mount Bracket Kit (Ø 6 ~ 7.5") Bracket: 241 x 161 mm (9.5 x 6.3")
Weight: 1.70 kg (3.75 lb)
Steel Strap Diameter: Ø 6 ~ 7.5"
GV-Mount501 Convex Corner Box Mount Dimensions: 136 x 256 x 256 mm (5.4 x 10.1 x10.1")
Weight: 4.8 kg (10.6 lb)
GV-Mount702 Extension Tube Four options are available.
Dimensions: Ø 5.4 x 10 or 20 or 30 or 50 cm
(Ø 2.1 x 3.9 or 7.9 or 11.8 or 19.7")
Weight: 180 g or 390 g or 550 g or 800 g
(0.4 lb or 0.86 lb or 1.21lb or 1.76 lb)
GV-Mount908-2 In-Ceiling Mounting Kit Dimensions: 205 x 128 x 227 mm (8.1 x 5 x 8.9")
Weight: 3 Kg (6.6 lb)
GV-PA901 PoE Adapter The GV-PA901 PoE adapter is designed to provide power and network connection to IP cameras over a single Ethernet cable.
Dimensions (L x W x H): 69 x 40 x 93 mm / 2.7 x 1.57 x 3.66"
Weight: 250 kg / 0.55 lb
Power Adapter Contact your sales representative for the countries and areas supported.
  • Panoramic PTZ IP Camera
  • Data Cable
  • Mounting Bracket
  • Mounting Cap
  • Tube
  • 2 mm Hex Key
  • 3 mm Hex Key
  • 5 mm Hex Key
  • Rubber Ring
  • RJ-45 Connector
  • Desiccant Pack x 2
  • GV-IPCAM Software DVD
  • GV-NVR Software DVD
  • Warranty Card​

Note:
  • Optional GV-PA901 PoE Adapter is required for applying PoE function.
  • Specifications are subject to change without notice.

GV-PPTZ7300 Product In Action

Introduction to GV-PPTZ7300

GV-PPTZ7300 - Installation - Straight Tube Mount


Note:
  • Optional GV-PA901 PoE Adapter is required for applying PoE function.
  • Specifications are subject to change without notice.
